Integrated Calendering and Slitting Machine

This equipment is used in the cutting process of lithium battery diaphragm.

Request for a Quotation

Product Model

  • ParameterSpecification
    Mechanical SpeedMAX:120m/min
    Roll Face WidthMAX:1400mm
    Cooling/Heating RollOptional
    Roller SpecificationΦ900×1500mm
    Mill Runout (No Load)≤±0.002mm
    Thickness Uniformity (After Rolling)≤±0.002mm
    Main Cylinder/Bend Cylinder Pressure700T/200T
    Guide Roller Installation Accuracy≤50μm
    Slitting Width Tolerance≤±0.3mm
    Slitting BurrLongitudinal：≤7μm   Transverse：≤14μm
    Winding Alignment Accuracy≤±0.5mm
    Yield Rate≥99.5%
    Equipment Failure Rate≤1%
    Anode (Negative Electrode)Integrated water-spraying, wiping & scraping roller structure
    Cathode (Positive Electrode)Tab calendaring (Optional)


Correlation Technique
