Flatbed Coating Machine (GW-level)
An industrial-grade coating solution specifically designed for GW-level perovskite production lines. It utilizes reliable precision coating technology and fully automated process control to achieve high uniformity and production stability for large-area thin films, thereby ensuring high yield in large-scale mass production.
-
Total Weight
16T
Coating Method
Slot-die Coating
Substrate size
1200mmx2400mm (Compatible with smaller sizes)
-
Coating Width
1200mm (Customizable)
Coating Uniformity
≤5%@(300~600nm)
Compatible Slurry Viscosity
1~70cp
-
Cycle time
75s@60mm/s
-
-
Small Flatbed Coating Machine (Laboratory Equipment)
A small flatbed coating machine for R&D laboratories, designed to meet the research needs of most perovskite solar cell manufacturers. It features a simple structure and user-friendly operation.
-
Energy Consumption
Low total power: 3KW
Coating Accuracy
±3%@400-500nm (±10 platinum loading)
Adaptable Substrate Size
300 x 400mm (Customizable)
-
Speed Fluctuation
0.5%@30mm/s
Footprint
1 m × 1.5 m = 1.5 m²
Safety
The whole machine is sealed, with air inlet and exhaust channels
-
-
Atmospheric Infrared Drying Oven
This is an atmospheric infrared drying oven designed and developed for the drying process in laboratory preparation of perovskite thin films. The device requires manual handling of glass sheets and achieves uniform drying by driving the carrier back and forth through a crank-link mechanism.
-
Substrate size
300mm*400mm
(Customizable)Temperature control
20℃: 35S
140℃: 55STemperature Accuracy
+3℃@120℃
±3℃@140℃
(the heating time depends on the power of infrared tube used) -
Safety
The whole machine is sealed, with air inlet and exhaust channels
-
-
Vacuum Infrared Tunnel Furnace
Designed for atmosphere-sensitive thin films such as perovskites, it combines rapid infrared heating with a high vacuum environment to achieve precise temperature field control, significantly reducing film defects and ensuring high yield and consistency of products, supporting continuous large-scale production.
-
Substrate size
Conventional pilot line size
Cycle time
90s
(Customizable)Temperature control
Heating chamber heating time:25S@80℃
Heating chamber temperature accuracy: ±7℃@80℃
(The heating time depends on the power of infrared tube used) -
Chamber sealing performance
When the pump stops, each chamber holds pressure for one minute, with a pressure increase of less than 10Pa
Safety
The whole machine is sealed, with air inlet and exhaust channels
-
-
Butyl Glue Dispensing Machine
The butyl glue dispensing machine achieves uniform and efficient dispensing of complex glue paths through high-precision dispensing control, fully automatic three-axis movement, and a stable temperature and pressure system, providing reliable airtight and watertight sealing assurance for products such as photovoltaic modules.
-
Maximum Heating Temperature
200°C
Dispensing Thickness
±0.1mm@0.7mm
Dispensing Width
±0.5mm@10mm
-
Dispensing Speed
100mm/s
Glass Size
635*1245mm
Temperature Accuracy
±3℃@180℃
-
Heating Time
35 min (RT→200°C)
Glue Supply Pressure
16Mpa
-
